CAPACITY

The systems are able to recognize 6 different codes. one Master code and five User codes. Each code has 1 to 6 digits combination.

OPERATION

Simply input correct code to open door. Status indication by LED for easy operation.

MEMORY

The system has build-in E²PROM memory to storage existing codes and functions for life avoid the inconvenience of repeating programming after power interruption.

SYSTEM ALARM

When entered 4 times incorrect codes consecutively, the beeper alarm will be activated automatically. The tamper switch will activate external alarm when system is being tampered.

With 2 output relays choices, alarm system can be switch off by the keypad. When alarm system is activated, the LED will be on.

INSTALLATION

The system can be installed on all kind of doors. Free setting of lock opening time from 0.5~49.5 seconds of free opening when activate by keypad.

POWER SUPPLY

Connected with 9~12V power supply. When electric strike, the system still can be operated while connected with the external power supply （UPS）.

CONSTRUCTION

Streamline and stylish appearance. Body is well constructed by ABS.

The water-resistant membrane keypad prevent from transfiguration, easy maintenance.
